84 Rockwell Automation Publication 1756-UM001M-EN-P - February 2012
Chapter 4 ControlLogix System and Controllers
Multiple Controllers in One Chassis
For some applications, multiple controllers may be used in one ControlLogix
chassis. For example, for better performance, multiple controllers can be used in
motion applications.
Figure 4 - Multiple Controllers in One Chassis
L75
L75
EN2T
EN2T
FactoryTalk ®Server
Stratix 8000â„¢ Switch
Kinetix 6500 Drive
Kinetix® 6500 Drive
Kinetix 6500 Drive
Motor
Motor
Motor
32045-MC
Ethernet
Ethernet
