1785-UM022B-EN-P - February 2002
Processor Status File B-3
S:11
S:10/04 Edits prevent SFC continuing; data table size changed during
program mode; reset automatically in run mode
S:10/05 Invalid I/O status file
S:10/06 reserved
S:10/07 No more command blocks exist to execute block-transfers
S:10/08 Not enough memory on the memory module to upload the program
from the processor
S:10/09 No MCP is configured to run
S:10/10 MCP not allowed
S:10/11 PII word number not in local rack
S:10/12 PII overlap
S:10/13 no command blocks exist to get PII
S:10/14 Arithmetic overflow
This word of
the status file:
Stores:
This word of
the status file:
Stores:
S:11 major fault word
S:11/00 Corrupted program file (codes 10-19). See major fault codes (S:12).
S:11/01 Corrupted address in ladder program (codes 20-29). See major
fault codes (S:12).
S:11/02 Programming error (codes 30-49). See major fault codes (S:12).
S:11/03 Processor detected an SFC fault (codes (71-79). See major fault
codes (S:12).
S:11/04 Processor detected an error when assembling a ladder program file
(code 70); duplicate LBLs found.
S:11/05 Start-up protection fault. The processor sets this major fault bit
when powering up in Run mode if the user control bit S:26/1 is set.
S:11/06 Peripheral device fault
S:11/07 User-generated fault; processor jumped to fault routine (codes 0-9).
See major fault codes (S:12).
S:11/08 Watchdog faulted
S:11/09 System configured wrong (codes 80 - 82, 84 - 88, 200 - 208). See
major fault codes (S:12).
S:11/10 Recoverable hardware error
S:11/11 MCP does not exist or is not a ladder or SFC file
