Allen-Bradley ControlNet PLC-5 User Manual

1785-UM022B-EN-P - February 2002
Processor Status File B-15
S:79-S127
This word of
the status file:
Stores:
S:79 MCP inhibit bits
Bit 0 for MCP A
Bit 1 for MCP B
etc.
S:80-S:127 MCP file number
MCP scan time (in ms)
MCP max scan time (in ms)
The above sequence applies to each MCP; therefore, each MCP has
3 status words.
For example, word 80: file number for MCP A
word 81: scan time for MCP A
word 82: maximum scan time for MCP A
word 83: file number for MCP B
word 84: scan time for MCP B
etc.
AB Drives

Allen-Bradley ControlNet PLC-5 Specifications

General

Manufacturer	Allen-Bradley
Network Type	ControlNet
Programming Software	RSLogix 5
Product Type	PLC
Communication Ports	ControlNet, DH+
Programming Languages	Ladder Logic
Operating Temperature	0°C to 60°C (32°F to 140°F)
Relative Humidity	5% to 95% (non-condensing)
Processor Type	PLC-5 Processor
Power Supply	24V DC
