Allen-Bradley ControlNet PLC-5 User Manual

1785-UM022B-EN-P - February 2002
2-34 Planning to Use Your ControlNet PLC-5 Processor
Converting from a Non-ControlNet
Remote I/O System to a ControlNet
I/O System
When you download archived files to a ControlNet PLC-5 processor,
the programming software ignores Channel 2 configuration
information from anything other than a ControlNet-processor
program because Channel 2 is reserved for ControlNet
communication on the ControlNet processors. The software sets
Channel 2 to the default ControlNet configuration.
Program files
1
for this process:
Archived from a: On channel:
Can be run on a
ControlNet
PLC-5 channel:
If they fit and are:
Messaging and I/O
•PLC-5/11
•PLC-5/20
• PLC-5/20C15
• PLC-5/20E
•PLC-5/30
•PLC-5/40
• PLC-5/40C15
• PLC-5/46C15
• PLC-5/40E
• PLC-5/40L
•PLC-5/60
• PLC-5/60L
•PLC-5/80
• PLC-5/80C15
• PLC-5/80E
0 0 downloaded unchanged
1A 1A
•PLC-5/20
• PLC-5/20C15
• PLC-5/20E
•PLC-5/30
•PLC-5/40
• PLC-5/40C15
• PLC-5/46C15
• PLC-5/40E
• PLC-5/40L
•PLC-5/60
• PLC-5/60L
•PLC-5/80
• PLC-5/80C15
• PLC-5/80E
1B 1B
• PLC-5/20C15
• PLC-5/40C15
• PLC-5/46C15
• PLC-5/80C15
22

Allen-Bradley ControlNet PLC-5 Specifications

General

Manufacturer	Allen-Bradley
Network Type	ControlNet
Programming Software	RSLogix 5
Product Type	PLC
Communication Ports	ControlNet, DH+
Programming Languages	Ladder Logic
Operating Temperature	0°C to 60°C (32°F to 140°F)
Relative Humidity	5% to 95% (non-condensing)
Processor Type	PLC-5 Processor
Power Supply	24V DC
