Processor Status File B-5
10 Run-time data table check failed
Recoverable:
the fault routine can instruct
the processor to clear the
fault and then resume
scanning the program.
A fault routine executes
when any of these faults
occur.
11 Bad user program checksum
12 Bad integer operand type, restore new processor memory file
13 Bad mixed mode operation type, restore new processor memory file
14 Not enough operands for instruction, restore new processor memory file
15 Too many operands for instructions, restore new processor memory file
16 Corrupted instruction, probably due to restoring an incompatible processor memory file (bad opcode)
17 Can’t find expression end; restore new processor memory file
18 Missing end of edit zone; restore new processor memory file
19 Download aborted
20 You entered too large an element number in an indirect address
21 You entered a negative element number in an indirect address
22 You tried to access a non-existent program file
23 You used a negative file number, you used a file number greater than the number of existing files, or you
tried to indirectly address files 0, 1, or 2
24 You tried to indirectly address a file of the wrong type
Recoverable
30 You tried to jump to one too many nested subroutine files
Non-recoverable:
the fault routine will be
executed but cannot clear
major fault bit 2.
31 You did not enter enough subroutine parameters
32 You jumped to an invalid (non-ladder) file
33 You entered a CAR routine file that is not 68000 code
34 You entered a negative preset or accumulated value in a timer instruction
Recoverable
35 You entered a negative time variable in a PID instruction
36 You entered an out-of-range setpoint in a PID instruction
37 You addressed an invalid module in a block-transfer, immediate input, or immediate output instruction
38 You entered a RET instruction from a non-subroutine file
Non-recoverable
the fault routine will be
executed but cannot clear
major fault bit 2.
39 FOR instruction with missing NXT
40 The control file is too small for the PID, BTR, BTW, or MSG instruction
Recoverable
This
fault
code: Indicates this fault: And the fault is:
