1785-UM022B-EN-P - February 2002
Processor Status File B-13
Important: Setting inhibit bits in the processor status file (S:27,
S:33, or S:35) does not update inhibit bits in the I/O
status file.
S:36-S:78
S:33 Rack control bits: (See also S:7, S:27, S:32, S:34, and S:35)
• S:33/0-7 I/O rack inhibit bits for racks 10-17
• S:33/8-15 I/O rack reset bits for racks 10-17
S:34 Global status bits: (See also S:7, S:27, S:32, S:33, and S:35)
• S:34/0-7 rack fault bits for racks 20-27 (octal)
• S:34/8-15 unused
S:35 Rack control bits: (See also S:7, S:27, S:32, S:33, and S:34)
• S:35/0-7 I/O rack inhibit bits for racks 20-27
• S:35/8-15 I/O rack reset bits for racks 20-27
This word of
the status file:
Stores:
This word of
the status file:
Stores:
S:36 - S:45 Reserved
S:46 PII program file number
S:47 PII module group
S:48 PII bit mask
S:49 PII compare value
S:50 PII down count
S:51 PII changed bit
S:52 PII events since last interrupt
S:53 STI scan time (in ms)
S:54 STI maximum scan time (in ms)
S:55 PII last scan time (in ms)
S:56 PII maximum scan time (in ms)
S:57 User program checksum
S:58 Reserved
S:59 Extended-local I/O channel discrete transfer scan (in ms)
S:60 Extended-local I/O channel discrete maximum scan (in ms)
S:61 Extended-local I/O channel block-transfer scan (in ms)
S:62 Extended-I/O channel maximum block-transfer scan (in ms)
S:63 Protected processor data table protection file number
