DeviceNet Objects (Class Code 0x0F — Parameter Object) C-13
Data Types for Instance Attribute 5
Common Services
Attribute
ID Value
Definition
Data Type
Description
Scaling Supported
on this Data Type
1 WORD 16-bit word No
2 UINT 16-bit unsigned integer Yes
3 INT 16-bit signed integer Yes
4 BOOL Boolean No
5 SINT Short integer Yes
6 DINT Double integer Yes
7 LINT Long integer Yes
8 USINT Unsigned short integer Yes
Service Code
Implemented for:
Service Name
Class Instance
0x01 No Yes Get_Attribute_All
0x0E Yes Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
0x4B No Yes Get_Enum_String
0x05 Yes No Reset_Request (sets
all parameters to
default values)
0x15 Yes No Restore_Request
0x16 Yes No Save_Request
