F-8 Supported Emulated Block Transfer Commands (Product ID Number Read)
Product ID Number Read Product ID Number Read returns the product ID of the device to
which the DeviceNet adapter is connected.
PLC Block Transfer Emulation Instruction Data
PLC request instruction length: 3 words
Drive response instruction length: 4 words
Figure F.5
Message Structure
Header
Word 0
PLC Decimal Value
256
Header
Word 1
Header
Word 2
PLC Request
Header Word 0
Header Word 1
Data Word 2
Message Length
Message Length
PLC Decimal Value
256 — Message OK
–32512 — Message Error
0
Drive Response
3
0
6
Data
Word 3
Product ID Number
Product Code
(Hex)
Product Code
(Decimal)
Bulletin
Number
Product
0x02 2 1336S 1336 PLUS 0.5 – 10 HP
0x03 3 1336S 1336 PLUS 7.5 – 800 HP
0x07 7 1336F 1336 PLUS II
0x10 16 1336T 1336 FORCE w/PLC Adapter Board
0x11 17 2364F 2364 RGU DC Bus Regen Front End
0x12 18 1394 1394 Motion Drive
0x13 19 1557 1557 Medium Voltage AC Drive
0x14 20 193 SMP-3
0x15 21 150 SMC Dialog Plus
0x17 23 1305 1305 AC Drive
0x18 24 1397 1397 DC Drive
0x19 25 1336R 1336 Line Regeneration Package
0x20 32 1336T 1336 FORCE w/Standard Adapter Board
0x22 34 1336E 1336 IMPACT
