Appendix A
Specifications
Appendix Objectives Appendix A provides the specifications that you may need to install
or use either the 1203-GK5 module or the 1336-GM5 board. These
adapters are non-repairable units. If they are broken, you must replace
the whole unit.
DeviceNet Conformance Tested Both the 1203-GK5 module and 1336-GM5 board are DeviceNet
Conformance Tested.
1203-GK5 Module Specifications The following table gives the specifications for the 1203-GK5
DeviceNet communications module.
➀
Inrush current may be four times the input current for 5 ms.
Category Specifications
Electrical Input Voltage
Input Current
SCANport Load
12 to 25 V DC
110 mA
➀
60 mA DC
Environmental Operating Temperature
Storage Temperature
Relative Humidity
0 to +50°C (32 to 122°F)
–40 to +85°C (–40 to 185°F)
0 to 95% non-condensing
Communications DeviceNet
Baud Rates
Distance Maximum
125, 250, 500 k BPS
500 m (1640 ft.) @ 125 k BPS
200 m (820 ft.) @ 250 k BPS
100 m (328 ft.) @ 500 k BPS
Mechanical Height
Width
Depth
Enclosure
DIN Rail Standard
76 mm (3.0 in.)
45 mm (1.8 in.)
123 mm (4.8 in.)
NEMA Type 1 (IP30)
35 mm x 7.5 mm (1.38 in. x 0.30 in.)
