DeviceNet Objects (Class Code 0x0F — Parameter Object) C-15
The table below lists the parameters for the Get_Enum_String request
service.
• If the string to be returned is a bit enumerated string, then the
enumerated string number represents a bit position and the
Get_Enum_String service returns a string from that bit.
• If the string to be returned is a value enumerated string, then the
enumerated string number represents a value and the
Get_Enum_String service returns a string for that value.
The enumerated string is returned in the form of a SHORT_STRING
and is 16 characters long plus the preceding length byte.
Name Data Type Description of Attribute
Enumerated String
Number
USINT Number of enumerated string to retrieve
(MAX value is 255).
