Allen-Bradley DeviceNet 1203-GK5 User Manual

C-24 DeviceNet Objects (Class Code 0x98 — SCANport Pass-Through Warning Object)
Common Services
128 Get Warning
Code and
Time Stamp
(Time Stamps
not available
in all
products)
STRUCT of
Warning
Code
WORD Fault Code.
Warning Time
Stamp (Time
Stamps not
available in all
products)
STRUCT of
BYTE 1/100 Second (0 – 99).
BYTE Second (0 – 59).
BYTE Minute (0 – 59).
BYTE Hour (0 – 23).
BYTE
Day of Week (0 – 6).
➀
BYTE Date (1 – 31).
BYTE Month (1 – 12).
BYTE
Year (0 – 99
➁
).
129 Get Read
Warning Text
String Only
ARRAY of
BYTE
16 character string (no length
information, no terminating
null).
Service Code
Implemented for:
Service Name
Class Instance
0x0E Yes Yes Get_Attribute_Single
0x01 Yes Yes Set_Attribute_Single
Attribute
ID
Access
Rule
Name Data Type Description
➀ Sunday is a value of zero.
➁ Year is an offset from 1990.
