Supported Emulated Block Transfer Commands (Fault Queue Entry Read Full) F-17
Message Operation
Fault Queue Entry Read Full reads the contents of the fault queue
specified in word 3 of the request. The response returns the fault text
which can be ASCII text. Every two characters of text are in reverse
order. Also, the 1336 FORCE drive returns a time stamp, indicating
the day and time the fault occurred.
If an error has occurred, word 1 of the response returns a negative
value.
Example
In this example, Fault Queue Entry number 3 was retrieved from a
1336 PLUS drive. The drive response returned the ASCII text Drive
Reset Flt, with each character reversed. The fault code for this
example is 22.
Data File Format
* Example only — These values vary depending on parameters and products.
0123456789
PLC request 3 1792 3*
Drive response 18 1792 3* 29252* 20313* 8293* 25938* 25971* 8308* 27718*
8303* 22*
Drive response \00\12 \07\00 \03\00 r D v i e e R e s t l F
t \00\16
