Creating a Ladder Logic Program 5-3
The 1305, 1336 PLUS, or 1336 PLUS II drive in this example accepts
the following Logic Command Data from the controller.
The 1305, 1336 PLUS, or 1336 PLUS II drive in this example sends
the following Logic Status Data to the PLC.
Logic Command Bits
Function Description
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
X Stop 1=Stop, 0=No Operation
X Start 1=Start, 0=No Operation
X Jog 1=Jog, 0=No Operation
X Clear Faults 1=Clear, 0=No Operation
X X Direction 00=No Operation, 01=Forward, 10=Reverse
X Local 1=Local, 0=Multiplexed
X MOP Increment 1=Increment MOP, 0=No Operation
X X Accel Rate Select 00=No Operation, 01=Rate 1, 10=Rate 2
X X Decel Rate Select 00=No Operation, 01=Rate 1, 10=Rate 2
XXX Reference
Selection
000=No Operation
001=External Reference 1 (Par 5)
010=External Reference 2 (Par 6)
011=Preset 3
100=Preset 4
101=Preset 5
110=Preset 6
111=Preset 7
X MOP Decrement 1=Decrement MOP, 0=No Operation
Logic Status Bits
Function Description
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
X Enabled 1=Enabled, 0=Not Enabled
X Running 1=Running, 0=Not Running
X Command Direction 1=Forward, 0=Reverse
X Rotating Direction 1=Forward, 0=Reverse
X Acceleration 1=Accelerating, 0=Not
X Deceleration 1=Decelerating, 0=Not
X Warning 1=Warning Present, 0=Not
X Fault 1=Faulted, 0=Not Faulted
X At Speed 1=At Speed, 0=Not At Speed
X X X Local 000=Terminal I/O has Local
001=Port 1 has Local
010=Port 2 has Local
011=Port 3 has Local
100=Port 4 has Local
101=Port 5 has Local
110=Port 6 has Local
111=Multiplexed Control
X X X X Reference Source 0000=External Reference 1
0001 – 0111=Presets 1 – 7
1000=External Reference 2
1001 – 1110=Port 1 – 6 Direction
1111=Jog
