DeviceNet Objects (Class Code 0x01 — Identity Object) C-3
Instance Attributes
Common Services
Get_Attribute_All Response
None supported.
Attribute ID Access Rule Name Data Type Description
1 Get Vendor ID UINT Identification of each vendor by number.
1 = Allen-Bradley
2 Get Device Type UINT Indication of general type of product.
0x69 = Sub-Component
0x65 = SCANport Device
3 Get Product Code UINT Identification of a particular Allen-Bradley product.
0xXX02 = 1336 PLUS 0.5 – 10 HP
0xXX03 = 1336 PLUS 7.5 – 800 HP
0xXX07 = 1336 PLUS II
0xXX10 = 1336 FORCE w/ PLC Adapter
0xXX11 = 2364F RGU
0xXX12 = 1394 Motion Drive
0xXX13 = 1557 Medium Voltage AC Drive
0xXX14 =193 SMP-3
0xXX15 = 150 SMC Dialog Plus
0xXX17 = 1305 AC Drive
0xXX18 = 1397 DC Drive
0xXX19 = 1336 REGEN
0xXX20 = 1336 FORCE with Std Adapter
0xXX22 = 1336 IMPACT
Important: The high byte of each code indicates a particular size
or configuration within a product family.
4 Get Revision STRUCT of Revision of the item that this instance of the Identity Object
represents.
Value varies based on product.
Major Revision USINT
Minor Revision USINT
5 Get Status WORD Summary status of product.
Value varies based on product.
6 Get Serial Number UDINT Serial number of product.
Value varies based on product.
7 Get Product Name SHORT_
STRING
Human readable identification.
Value varies based on product.
Service Code
Implemented for:
Service Name
Class Instance
0x05 Yes No Reset
0x0E Yes Yes Get_Attribute_Single
0x10 No No Set_Attribute_Single
0x11 Yes N/A Find_Next_Obj_Instance
