DeviceNet Objects (Class Code 0x05 — Connection) C-7
Instance Attributes
Common Services
Not supported.
Attribute ID Access Rule Name Data Type Description
1 Get State USINT State of the connection as defined in the DeviceNet
specification
2 Get Instance type USINT Indicates I/O or Messaging connection
3 Get Transport Class Trigger USINT The Transport Class Trigger for this instance
4 Get Produced Cnxn ID USINT CAN Identifier to transmit on
5 Get Consumed Cnxn ID USINT CAN Identifier to receive on
6 Get Initial Comm Char USINT Defines the DeviceNet message groups that the tx/rx
Cnxn’s apply
7 Get Produced Cnxn Size UINT Max bytes to transmit across this connection
8 Get Consumed Cnxn Size UINT Max bytes to receive across this connection
9 Get/Set EPR UINT Expected Packet Rate
12 Get/Set Watchdog Action USINT How to handle inactivity/watchdog time-outs
13 Get Produced Path Length UINT Number of bytes in the produced connection path
attribute
14 Get Produced Cnxn Path ARRAY of USINT Specifies the application object whose data is to be
produced by this connection
15 Get Consumed Path Length UINT Number of bytes in the consumed connection path
attribute
16 Get Consumed Cnxn Path ARRAY of USINT Specifies the application object to receive the data
consumed by this application
