Rockwell Automation Publication ENET-UM004B-EN-P - November 2015 27
Configure an EtherNet/IP Communication Module Chapter 3
Set the Network IP Address
on a Module
You can use the following tools to set the network Internet Protocol (IP) address.
• Rotary switches - If the network uses 192.168.1.x, we recommend using
the rotary switches to set the last octet of network IP address.
Valid numbers range from 001…254. The switches are only for setting
192.168.1.xxx IP addresses.
Switch changes are recognized only at module power-up.
For more information, see the 5069 Compact I/O EtherNet/IP Adapter
Installation Instructions, publication
5069-IN003.
• BOOTP/DHCP server
For more information, see
Set the Network IP Address with the BOOTP/
DHCP Server on page 28.
• RSLinx® Classic software
For more information, see
Configure the Adapter with RSLinx Classic
Software through the USB Port on page 32.
EtherNet/IP communication modules are shipped with this configuration:
• BOOTP/DHCP enabled
• Rotary switches set to 000 - when applicable
WARNING: When you change switch settings while power is on, an electrical
arc can occur. This could cause an explosion in hazardous location
installations. Be sure that power is removed or the area is nonhazardous
before proceeding.
