Rockwell Automation Publication ENET-UM004B-EN-P - November 2015 5
Preface
This manual describes how to use EtherNet/IP communication modules in
Logix5000™ control systems.
Make sure that you are familiar with the following:
• Use of a controller in a Logix5000 control system
• Use of an EtherNet/IP network, if the analog I/O modules are installed in
a remote location from the controller that is accessible via the |
EtherNet/IP network
• Studio 5000 Logix Designer® environment
• RSLinx® Classic software
Additional Resources
These documents contain more information concerning related products from
Rockwell Automation.
IMPORTANT
Remember the following when you use 5000 series EtherNet/IP
communication modules:
• You cannot use 5000 series EtherNet/IP communication modules with all
Logix5000 controllers. For example, you can use the 5069-AEN2TR
EtherNet/IP adapter with ControlLogix® 5580 controllers but not with
ControlLogix 5570 controllers.
For more information on which Logix5000 controllers that you can use with
5000 series EtherNet/IP communication modules, see the product
description at
http://www.ab.com.
• You must use the Logix Designer application, version 28 or greater, to
configure the 5000 series analog I/O modules.
Table 1 - Additional Resources
Resource Description
5069 Compact I/O EtherNet/IP Adapter
Installation Instructions, publication
5069-IN003
Describes how to install the 5069-AEN2TR EtherNet/IP adapter in a 5069
Compact I/O™ system.
5069 Compact I/O Modules Specifications
Technical Data, publication
5069-TD001
Provides 5069-AEN2TR EtherNet/IP adapter and 5069 Compact I/O
module specifications.
EtherNet/IP Media Planning and
Installation Manual
Describes how to use the required media components and how to plan
for, install, verify, troubleshoot, and certify your EtherNet/IP network.
This manual is available from the Open DeviceNet Vendor Association
(ODVA) at: http://www.odva.org.
