78 Rockwell Automation Publication 2080-UM005B-EN-E - March 2015
Chapter 8 Using the Micro800 Remote LCD
The controller limits certain operations according to controller mode, as shown
in the following table.
View and Edit Variable Values through the Remote LCD
Go to the 2080-REMLCD configuration window in Connected Components
Workbench. Click LCD Variables and select which variables you would like to
edit through the Remote LCD.
Main Menu Items
Menu Item Description
I/O Status Shows the status of the local I/O.
Mode switch Change the mode switch selection.
Variables View and change the data value of a variable. Using Connected Components
Workbench software, you can specify which variables in the program can be
viewed and edited through the 2080-REMLCD module.
See View and Edit Variable Values through the Remote LCD on page 78.
Security Activate, deactivate and change password protection.
Advanced Set System Info View system information such as operating
systems series and firmware revision.
Fault Code View controller fault code information.
LCD Setup Adjust LCD contrast, backlight color and
push button.
Clock Setup The real-time clock and daylight saving time.
Language Change menu language to French, Italian,
Spanish, and Chinese.
Analog Calibration Configure calibration parameter of embedded
analog inputs.
PwrUp Behavior Configure controller mode on powerup.
Memory Card Access the microSD card.
ENET Cfg View and change the Ethernet port configuration.
Operational Limit on 2080-REMLCD
Operation PROG Mode RUN Mode
Variable Edit NO YES
Analog Calibration YES NO
Controller → Memory Card YES NO
Memory Card → Controller YES NO
Others YES YES
