Rockwell Automation Publication 2080-UM002K-EN-E - March 2019 307
Troubleshooting Appendix E
0xF006 Recoverable The user program is incompatible with the
Micro800 controller’s firmware revision.
Perform one of the following:
• See Corrective Actions for Recoverable Faults
on page 313.
• Contact your local Rockwell Automation technical support
representative.
0xF010 Recoverable The user program contains a function/function
block that is not supported by the Micro800
controller.
Perform one of the following:
• See Corrective Actions for Recoverable Faults
on page 313.
• Contact your local Rockwell Automation technical support
representative.
0xF014 Recoverable A memory module memory error occurred. • See Corrective Actions for Recoverable Faults on page 313.
• Reprogram the memory module. If the error persists, replace the
memory module.
0xF015 Non-
recoverable
An unexpected software error occurred. Perform one of the following:
• See Corrective Actions for Non-recoverable Faults
on page 313.
• Refer to Wiring Requirements and Recommendation
on page 41.
0xF016 Non-
recoverable
An unexpected hardware error occurred. Perform one of the following:
• See Corrective Actions for Non-recoverable Faults
on page 313.
• Refer to Wiring Requirements and Recommendation on page 41.
0xF017 Non-
recoverable
An unexpected software error occurred due to
unexpected hardware interrupt.
If the system variable
_SYSVA_USER_DATA_LOST is set, the controller
is able to recover the user program but the user
data is cleared. If not, the Micro800 controller
program is cleared.
Perform one of the following:
• See Corrective Actions for Non-recoverable Faults
on page 313.
• Refer to Wiring Requirements and Recommendation on page 41.
0xF018 Non-
recoverable
An unexpected software error occurred due to SPI
communication failure.
If the system variable
_SYSVA_USER_DATA_LOST is set, the controller
is able to recover the user program but the user
data is cleared. If not, the Micro800 controller
program is cleared.
Perform one of the following:
• See Corrective Actions for Non-recoverable Faults on page 313.
• Refer to Wiring Requirements and Recommendation on page 41.
0xF019 Non-
recoverable
An unexpected software error occurred due to
memory or other controller resource issue.
See Corrective Actions for Non-recoverable Faults
on page 313.
0xF01A Recoverable The controller was unexpectedly reset during Run
Mode Change (RMC) due to a noisy environment
or an internal hardware failure.
If the system variable
_SYSVA_USER_DATA_LOST is set, the controller
is able to recover the user program but the user
data is cleared. If not, the Micro800 controller
program is cleared.
See Corrective Actions for Recoverable Faults
on page 313.
0xF020 Recoverable The base hardware faulted or is incompatible
with the Micro800 controller’s firmware revision.
See Corrective Actions for Recoverable Faults
on page 313.
0xF021 Recoverable The I/O configuration in the user program is
invalid or does not exist in the Micro800
controller.
See Corrective Actions for Recoverable Faults
on page 313.
0xF022 Recoverable The user program in the memory module is
incompatible with the Micro800 controller’s
firmware revision.
Perform one of the following:
• See Corrective Actions for Recoverable Faults
on page 313.
• Replace the memory module.
List of Error Codes for Micro800 controllers
Error Code Fault Type Description Recommended Action
