Publication 1762-RM001C-EN-P
Data Logging (MicroLogix 1500 1764-LRP Processor only) 22-5
For queue 5, the formatted string length is 29 characters, as shown below:
= 8 + 1 + 6 + 1 + 6 + 1 + 6 = 29 characters
Number of Records
Using Queue 5 as an example, each record consumes:
Each record consumes 10 bytes. So if only one queue was configured, the
maximum number of records that could be stored would be 4915. The
maximum number of records is calculated by:
Maximum Number of Records = Data Log File Size/Record Size
= 48K bytes/10 bytes
= (48)(1024)/10
= 4915 records
Data Time N7:11 I1:3.0 I1:2.1
Characters 8 1 6 1 6 1 6
Record Field Memory Consumption
Time 2 bytes
N7:11 2 bytes
I1:3.0 2 bytes
I1:2.1 2 bytes
Integrity Check 2 bytes
Total 10 bytes
