MicroLogix 1762-IF4 Analog Input Module 19
Publication 1762-IN012C-EN-P - June 2013
Error Codes
The 1762-IF4 module notifies the controller of critical and non-critical errors. The module
condition array word 0 contains the error codes that are generated by the module, as shown
below.
The table below describes the module error codes.
“Don’t Care” Bits Module Error Extended Error Information
1514131211109876543210
0 0 0 0 0 0 0000000000
Hex Digit 4 Hex Digit 3 Hex Digit 2 Hex Digit 1
Error Type Hex
Equivalent
(1)
(1)
X represents “Don’t Care”.
Module
Error Code
Extended Error
Information Code
Error Description
Binary Binary
No Error X000 000 0 0000 0000 No error
General Common
Hardware Error
X200 001 0 0000 0000 General hardware error; no
additional information
X201 001 0 0000 0001 Power-up reset state
Hardware-
Specific Error
X300 001 1 0000 0000 Reserved
Configuration
Error
X400 010 0 0000 0000 General configuration error; no
additional information
X401 010 0 0000 0001 Invalid range select (Channel 0)
X402 010 0 0000 0010 Invalid range select (Channel 1)
X403 010 0 0000 0011 Invalid range select (Channel 2)
X404 010 0 0000 0100 Invalid range select (Channel 3)
X405 010 0 0000 0101 Invalid filter select (Channel 0)
X406 010 0 0000 0110 Invalid filter select (Channel 1)
X407 010 0 0000 0111 Invalid filter select (Channel 2)
X408 010 0 0000 1000 Invalid filter select (Channel 3)
X409 010 0 0000 1001 Invalid format select (Channel 0)
X40A 010 0 0000 1010 Invalid format select (Channel 1)
X40B 010 0 0000 1011 Invalid format select (Channel 2)
X40C 010 0 0000 1100 Invalid format select (Channel 3)
