MicroLogix 1762-IF4 Analog Input Module 21
Publication 1762-IN012C-EN-P - June 2013
General
Attribute Value
Dimensions, HxWxD 90 x 40.4 x 87 mm
(3.54 x 1.59 x 3.43 in.)
Approximate shipping weight (with carton) 235 g (8.28 oz)
Bus current draw, max 40 mA @ 5V DC
50 mA @ 24V DC
Analog normal operating range Voltage: -10…10V DC
Current: 4…20 mA
Full scale
(1)
analog ranges
(1)
The over- or under-range flag comes on when the normal operating range (over/under) is exceeded. The module continues
to convert the analog input up to the maximum full scale range.
Voltage: -10.5…10.5V DC
Current: -21…21 mA
Resolution 15 bits (bipolar)
Repeatability
(2)
(2)
Repeatability is the ability of the input module to register the same reading in successive measurements for the same input
signal.
±0.12%
Input group to system isolation
30V AC/30V DC rated working voltage
(4)
(IEC Class 2 reinforced insulation)
type test: 500V AC or 707V DC for 1 min
(4)
Rated working voltage is the maximum continuous voltage that can be applied at the terminals with respect to earth
ground.
Module power LED On: indicates power is applied.
Recommended cable Belden 8761 (shielded)
Vendor ID code 1
Product type code 10
Product code 67
Wire size See Wire Size and Terminal Screw Torque
on page 15
Wiring category
(3)
(3)
Use this Conductor Category information for planning conductor routing. Refer to Industrial Automation Wiring and
Grounding Guidelines, publication 1770-4.1
.
2 - on signal ports
Pilot duty rating Not rated
Enclosure type rating IP20
North American temp code T3C
