40061-325-01(D)
Installation Instructions
English
PanelView 550 Terminals
(Catalog Numbers 2711-K5Axx, 2711-B5Axx)
Inside:
For More Information.............................................................................. 4
Hazardous Locations............................................................................... 4
European Union Directive Compliance ................................................... 5
Wiring and Safety Guidelines................................................................. 6
Enclosures............................................................................................... 6
Required Tools......................................................................................... 6
Mounting Dimensions............................................................................. 7
Cutout Dimensions.................................................................................. 7
Clearances .............................................................................................. 8
Installing Terminal in a Panel.................................................................. 9
Installing the Memory Card .................................................................. 11
Connecting AC Power........................................................................... 12
Connecting DC Power........................................................................... 13
