46 Rockwell Automation Publication 2711R-UM001E-EN-E - January 2017
Chapter 2 Configuration Mode
The name of the currently loaded application is displayed, as well as a list
of the recipes for that application.
5. Select the recipe from the recipe list.
6. Press Delete if you wish to delete the recipe, then press OK to confirm.
7. Press the blue area next to Name to change the name of the recipe.
8. Type in the desired name using the on-screen keypad, then press Enter.
Renaming of a recipe in a design secured application is not
allowed.
Deletion of a recipe in a design secured application is not
allowed.
Edit Recipe
Back
Delete
Application Name:
Name:
Recipe1
Recipe2
Recipe1
Recipe3
Recipe4
PVcApplication1
`
Esc F1 F2 F3 F4 F5 F6 F7 F8 F9 F10 F11 F12 Home End
1 2 3
4
5 6
7
8
9
0
- =
q w e
r
t y
u
i
o
p
[ ]
\
Recipe4
Caps
a s d
f
g h
j
k
l
;
’
Shift
z x c
v
b n
m
,
.
/
Ctrl
Win
Alt
ins
del
To Next Page
