Allen-Bradley PanelView 800 2711R-T4T User Manual

Rockwell Automation Publication 2711R-UM001E-EN-E - January 2017 11
Chapter 1
Overview
Chapter Objectives
This chapter gives an overview of the PanelView 800 terminals.
•About the terminals
• How to connect browser
(1)
•PanelView Explorer
(2)
•How to display help
•Peripheral connection
• Catalog number configuration
About the Terminals
PanelView 800 terminals are operator interface devices for monitoring and
controlling devices attached to a controller. HMI applications are created using
Connected Components Workbench software, then downloaded to the
terminal.
PanelView 800 Terminal – 2711R-T4T
(1)
The web browser feature is not supported on PanelView 800 terminals from firmware revision 3.011 onwards.
(2)
The PanelView Explorer feature is not supported on PanelView 800 terminals from firmware revision 3.011
onwards.
2
3
4
6
1
76
5
8
9
10
11
12

Allen-Bradley PanelView 800 2711R-T4T Specifications

General

Brand	Allen-Bradley
Model	PanelView 800 2711R-T4T
Category	Touch terminals
Language	English
