Allen-Bradley PanelView 800 2711R-T4T User Manual

12 Rockwell Automation Publication 2711R-UM001E-EN-E - January 2017
Chapter 1 Overview
PanelView 800 Terminals – 2711R-T7T
Item Description Item Description
1
Power status LED
(1)
(1)
The Power Status LED is red when in screen saver or dimmer mode and green when in normal (operational)
mode.
7 10/100 Mbit Ethernet port
2 Touch display, function keys 8 RS-232 port
3 24V DC power input 9 RS-422 and RS-485 port
4
USB device port
(2)
(2)
The USB device port is not intended for Customer use.
10 USB host port
5 Micro-SD (Secure Digital) card slot 11 Diagnostic status indicator
6 Mounting slots 12 Replaceable real-time clock battery
Item Description Item Description
1
Power status LED
(1)
(1)
The Power Status LED is red when in screen saver or dimmer mode and green when in normal (operational)
mode.
7 Replaceable real-time clock battery
2 Touch display 8 USB host port
3 Mounting slots 9 Diagnostic status indicator
4 RS-422 and RS-485 port 10 Micro-SD (Secure Digital) card slot
5 RS-232 port 11 24V DC power input
6 10/100 Mbit Ethernet port 12
USB device port
(2)
(2)
The USB device port is not intended for Customer use.
1
5643
8
7
10
92
3
11
12

Allen-Bradley PanelView 800 2711R-T4T Specifications

General

Brand	Allen-Bradley
Model	PanelView 800 2711R-T4T
Category	Touch terminals
Language	English
