Rockwell Automation Publication 2711R-UM001E-EN-E - January 2017 71
Cable Connections and Communication Chapter 4
Micro800 Controller Cable
Charts
The chart provides a summary of terminal connections to controllers and
network interface modules.
CompactLogix 5370
Controller Cable Charts
Support for communication with CompactLogix™ 5370 L1 controllers has been
added from firmware revision 3.011 onwards. Support for communication with
CompactLogix 5370 L2 and L3 controllers have been added from firmware
revision 4.012 onwards. This feature also requires Connected Components
Workbench Release 9 or later software to be installed.
The chart provides a summary of terminal connections to controllers and
network interface modules.
For more information on adding CompactLogix 5370 controllers to your
applications, refer to the PVc DesignStation help in Connected Components
Workbench on the following topics.
• Configuring communication settings for CompactLogix 5370 controllers.
• Mapping tags from CompactLogix 5370 controllers to PanelView 800
terminals.
• Validating an application that includes a CompactLogix 5370 controller.
PanelView 800 Terminal Connections to Micro800 Controllers
Protocol PanelView 800
Port
Micro820 Micro830 Micro850
Modbus RS-232
–
(2)
1761-CBL-PM02 1761-CBL-PM02
RS-485
(1)
–
(2)
–
(2)
–
(2)
Ethernet 2711P-CBL-EX04
(CAT5 Ethernet)
N/A 2711P-CBL-EX04
(CAT5 Ethernet)
Ethernet (AB CIP) Ethernet 2711P-CBL-EX04
(CAT5 Ethernet)
N/A 2711P-CBL-EX04
(CAT5 Ethernet)
Serial (AB CIP) RS-232
–
(2)
1761-CBL-PM02 1761-CBL-PM02
(1)
RS485 is isolated. It is recommended to only connect one device.
(2)
Terminal block, wiring required.
PanelView 800 Terminal Connections to CompactLogix 5370 Controllers
Protocol (CIP) PanelView 800 Port CompactLogix 5370
Ethernet
(CompactLogix)
2711P-CBL-EX04
(CAT5 Ethernet)
2711P-CBL-EX04
(CAT5 Ethernet)
