Publication 2711P-UM001A-EN-P
A-2 Specifications
Mechanical
Agency Certifications
Weight (for base unit without modules)
700 Keypad or Keypad & Touch
700 Touch
1000 Keypad or Keypad & Touch
1000 Touch
1250 Keypad or Keypad & Touch
1250 Touch
1500 Keypad or Keypad & Touch
1500 Touch
1.9 kg (4.2 lbs)
1.7 kg (3.8 lbs)
2.9 kg (6.3 lbs)
2.6 kg (5.7 lbs)
3.4 kg (7.6 lbs)
3.2 kg (7.1 lbs)
4.6 kg (10.0 lbs)
4.2 kg (9.3 lbs)
Dimensions H x W x D (for base unit without communication module)
700 Keypad or Keypad & Touch 193 x 290 x 55 mm
7.58 x 11.40 x 2.18 in
700 Touch 179 x 246 x 55 mm
7.04 x 9.68 x 2.18 in
1000 Keypad or Keypad & Touch 248 x 399 x 55 mm
9.77 x 15.72 x 2.18 in
1000 Touch 248 x 329 x 55 mm
9.77 x 12.97 x 2.18 in
1250 Keypad or Keypad & Touch 282 x 416 x 55 mm
11.12 x 16.36 x 2.18 in
1250 Touch 282 x 363 x 55 mm
11.12 x 14.30 x 2.18 mm
1500 Keypad or Keypad & Touch 330 x 469 x 65 mm
12.97 x 18.46 x 2.55 in
1500 Touch 330 x 416 x 65 mm
12.97 x 16.37 x 2.55 in
Agency Certifications
When product is marked:
N223
Marked for all applicable directives
Marked for all applicable acts
UL Listed Industrial Control Equipment
UL Listed Industrial Control Equipment for use in Canada
UL Listed Industrial Control Equipment for use in:
• Class I, Div 2 Group A, B, C, D
• Class II, Div 2 Group F, G
• Class III, Div 1 Hazardous Locations
