POINT I/O EtherNet/IP Adapter 19
Publication 1734-IN042F-EN-P - November 2018
(2)
Use the Conductor Category information for planning conductor routing as described in the appropriate System Level
Installation Manual.
At the end of its life, this equipment should be collected separately from any
unsorted municipal waste.
Power Supply
Attribute Value
Input voltage rating 24V DC @ 10 A
Input voltage, range 10...28.8V DC
Field side power requirements, max 24V DC @ 400 mA
Inrush current, max 6.0A for 10ms
Input overvoltage protection Reverse polarity protected
POINTBus output current, max 5V DC @ 1.0A
Interruption Output voltage stays within specifications when input drops out
for 10ms @ 10V with maximum load.
Ethernet Communication
Attribute Value
Ethernet communication rate 10/100 Mbits/s, half or full-duplex
Ethernet ports 1
Ethernet network topologies supported Star, Tree
Ethernet connector RJ-45, Category 5
Ethernet cable Category 5:
shielded or unshielded
Ethernet wire connections, max See Wire Size
on page 18
