10 Rockwell Automation Publication 22-TD001I-EN-P - June 2013
PowerFlex 4 and 40 AC Drives
User Installed Options
IP30/NEMA 1/UL Type 1 Conversion Kit
Human Interface Module Option Kits and Accessories
Communication Option Kits
Item Description
Drive
Frame
PowerFlex 4 PowerFlex 40
Catalog Number
(1)
(1) For pricing information, refer to the PowerFlex 4 Price List, publication 22A-PL001 and PowerFlex 40 Price List, publication 22B-PL001.
Catalog Number
(1)
IP30/NEMA 1/UL Type 1 Kit Field installed kit. Converts drive to IP30/NEMA 1/UL Type 1 enclosure. Includes conduit box with mounting
screws and plastic top panel.
A22-JBAA –
B 22-JBAB 22-JBAB
C–
22-JBAC
IP30/NEMA 1/UL Type 1 Kit with
Communication Option
Field installed kit. Converts drive to IP30/NEMA 1/UL Type 1 enclosure. Includes communication option
conduit box with mounting screws and plastic top panel.
B – 22-JBCB
C – 22-JBCC
Item Description Catalog Number
(1)
(1) For pricing information, refer to the PowerFlex 4 Price List, publication 22A-PL001 and PowerFlex 40 Price List, publication 22B-PL001.
Remote Human Interface Modules
(HIMs)
LCD Display, Remote Panel Mount, Digital Speed Control, CopyCat capable, IP66
(NEMA Type 4X/12) indoor use only. Includes 2.0 meter cable.
22-HIM-C2S
LCD Display, Remote Handheld, Digital Speed Control, Full Numeric Keypad, CopyCat capable, IP30
(NEMA Type 1). Includes 1.0 meter cable. Can be panel mounted with optional Bezel Kit.
22-HIM-A3
Remote Handheld, Wireless Interface Module with Bluetooth® technology, IP30 (NEMA Type 1).
Panel Mount with optional Bezel Kit.
22-WIM-N1
Remote Panel Mount, Wireless Interface Module with Bluetooth® technology, IP66 (NEMA Type 4X/12)
indoor use only.
22-WIM-N4S
Bezel Kit Panel Mount for LCD Display, Remote Handheld unit, IP30 (NEMA Type 1). Includes a 22-RJ45CBL-C20 cable. 22-HIM-B1
DSI HIM Cable DSI HIM Cable (DSI HIM to RJ45 cable)
• 1.0 Meter (3.3 Feet)
• 2.9 Meter (9.51 Feet)
22-HIM-H10
22-HIM-H30
Item Description Catalog Number
(1)
(1) For pricing information, refer to the PowerFlex 4 Price List, publication 22A-PL001 and PowerFlex 40 Price List, publication 22B-PL001.
Serial Converter Module (RS485
to RS232)
Provides serial communication via DF1 protocol for use with DriveExplorer™ and DriveExecutive™ software. Smart Self-powered Serial
Converter (RS-232) includes:
• DSI to RS232 serial converter
• DriveExplorer Lite Version 3.01 or later
• 1203-SFC and 22-RJ45CBL-C20 Cables
22-SCM-232
Serial Cable 2.0 meter serial cable with a locking low profile connector to connect to the serial converter and a 9-pin sub-miniature D female connector
to connect to a computer.
1203-SFC
Null Cable Converter For use when connecting the serial converter to DriveExplorer on a handheld PC. 1203-SNM
Universal Serial Bus™ (USB)
Converter
Provides a direct, isolated USB connection for use with DriveExplorer and DriveExecutive software. Includes 2.0 meter USB cable, 20-HIM-
H10 and 22-HIM-H10 cables.
1203-USB
DSI Cable 2.0 meter RJ45 to RJ45 cable, male to male connectors. 22-RJ45CBL-C20
Splitter Cable RJ45 one to two port splitter cable. AK-U0-RJ45-SC1
Terminating Resistors RJ45 120 Ohm resistor (2 pieces). AK-U0-RJ45-TR1
Terminal Block RJ45 Two position terminal block (6 pieces). AK-U0-RJ45-TB2P
External DSI Communications Kit External communications kit for 22-COMM Communication Adapters. Multi-Drive capability allows connectivity for up to 5 drives. 22-XCOMM-DC-BASE
External Comms Power Supply Optional 100…240V AC power supply for external DSI communications kit. 20-XCOMM-AC-PS1
Communication Adapters Embedded communication option for use with the PowerFlex family of drives.
Requires a Communication Adapter Cover (Ordered Separately).
• BACnet
• ControlNet
• DeviceNet
• EtherNet/IP
• LonWorks
• PROFIBUS DP
22-COMM-B
22-COMM-C
22-COMM-D
22-COMM-E
22-COMM-L
22-COMM-P
Compact I/O Module Provides 3 channels that can be individually configured for Single, Multi-Drive, and Modbus RTU modes. 1769-SM2
Communication Adapter Covers Houses the optional communication adapters. These covers add 25 mm (0.98 in.) to the overall depth of the drive.
• PowerFlex 40 Drive Frame B
• PowerFlex 40 Drive Frame C
22B-CCB
22B-CCC
Shaded areas are applicable to PowerFlex 40 only.
