Allen-Bradley PowerFlex 40 Original Instructions

Rockwell Automation Publication 22-TD001I-EN-P - June 2013 31
PowerFlex 4 and 40 AC Drives
Human Interface Module (HIM) Dimensions
93
(3.66)
25.2
(0.99)
2m
180
(7.09)
11.1
(0.44)
19.1
(0.75)
4.8
(0.19)
154
(6.06)
77
(3.03)
23.5
(0.93)
67
(2.64)
60
(2.36)
93,0
(3.66)
25,0
(0.98)
2.0m
mm
(in.)
180,0
(7.08)
19.1
(0.75)
4.8
(0.19)
154
(6.06)
77
(3.03)
23.5
(0.93)
67
(2.64)
60
(2.36)
NEMA Type 1 Bezel – Dimensions are in millimeters and (inches)
Catalog Number: 22-HIM-B1
NEMA Type 4X/12 Remote (Panel Mount) HIM
– Dimensions are in millimeters and (inches)
Catalog Number: 22-HIM-C2S
Aotewell Ltd
www.aotewell.com
Industry Automation
HongKong|UK|China
sales@aotewell.com
+86-755-8660-6182
http://www.aotewell.com/

Allen-Bradley PowerFlex 40 Specifications

General

Output Voltage	0 to Input Voltage
Enclosure	IP20
Control Method	V/Hz, Sensorless Vector Control
Communication	RS485
Frequency	0 to 400 Hz
Protection	Overload, Overvoltage, Undervoltage, Short Circuit
Operating Temperature	-10 to 50°C (14 to 122°F)
Storage Temperature	-40...70 °C (-40...158 °F)
Humidity	5% to 95% non-condensing
Input Voltage	200-240V AC, 380-480V AC, 500-600V AC (depending on model)
