Allen-Bradley PowerFlex 40 - Enclosure Options and Approximate Dimensions

36 Rockwell Automation Publication 22-TD001I-EN-P - June 2013
PowerFlex 4 and 40 AC Drives
Enclosure Options and Approximate Dimensions
355.6
(14.00)
9.4
(0.37)
393.2
(15.48)
405.9
(15.98)
336.6
(13.25)
298.5
(11.75)
177.8
(7.00)
69.3
(2.73)
355.1
(13.98)
342.4
(13.48)
304.8
(12.00)
285.8
(11.25)
Optional mounting bracket orientation.
6.35
(0.25)
