Rockwell Automation Publication 22-TD001I-EN-P - June 2013 7
PowerFlex 4 and 40 AC Drives
Use the chart below to assist in determining which product is most appropriate for an application.
Feature
Catalog Reference 22A 22B
Maximum (kW)HP Rating/Input Voltage
(1.1) 1.5 HP/115V, 1ø (1.1) 1.5 HP/115V, 1ø
(2.2) 3 HP/230V, 1ø (2.2) 3 HP/230V, 1ø
(3.7) 5 HP/230V, 3ø (7.5) 10 HP/230V, 3ø
(3.7) 5 HP/460V, 3ø (11.0) 15 HP/460V, 3ø
(11.0) 15 HP/600V, 3ø
Overload Capacity
150% for 60 seconds
200% for 3 seconds
150% for 60 seconds
200% for 3 seconds
IP30, NEMA/UL Type 1 Option ●●
IP66, NEMA/UL Type 4X/12 (Indoor) ●
(2)
(2) Frame B only.
EMC Filtering
Internal - 1ø, 230V
External - All 1ø, 115V and 3ø Ratings
Internal - 1ø, 230V
External - All 1ø, 115V and 3ø Ratings
DIN Rail Mounting Standard
●●
(Through 5 HP)
Integral Keypad with Speed Pot ●●
Keypad - Remote LCD ●●
Keypad CopyCat Function ●●
Control Type V/Hz Sensorless Vector & V/Hz
Internal DB Transistor
●
Not available on no brake models.
●
Preset Speeds 48
Carrier Frequency 2…16 kHz 2…16 kHz
Skip Frequency ●
Process Control Loop
●
(PID)
StepLogic Functionality ●
Timer/Counter Functions ●
Control Voltage 24V sink/source 24V sink/source
Discrete Inputs
3 fixed for START/STOP/REV 3 fixed for START/STOP/REV
2 fully programmable 4 fully programmable
Analog Input - Unipolar
1
(0…10V or 4…20 mA)
2
(0…10V and 4…20 mA)
Analog Input - Bipolar
1
(+/- 10V)
(3)
(3) When using bipolar input, the 0…10V unipolar input cannot be used.
Analog Response 2 Hz (500 ms) 100 Hz (10 ms)
Relay Output 1 - N.O/N.C. dry contact 1 - N.O./N.C. dry contact
Digital/Optocoupler Output 2
Analog Output
●
(0…10V or 4…20 mA)
Integral RS485 ●●
RS232 (Requires use of Serial Converter Module) ●●
BACnet ●
(1)
(1) With 22-XCOMM-DC-BASE External mounting kit.
●
ControlNet ●
(1)
●
DeviceNet ●
(1)
●
EtherNet/IP ●
(1)
●
LonWorks ●
(1)
●
PROFIBUS DP ●
(1)
●
To Next Page
