Appendix B Accessories and Dimensions
Replacement Parts
PowerFlex 520-Series Power Module
Item Description
PowerFlex 520-Series
Power Module
Replacement power module for use with PowerFlex 520-Series drives. Includes:
• Power Module
• Power Module Front Cover
• Power Terminal Guard
• Heatsink Fan
Output Ratings
Input
Voltage Range
Frame
Size Catalog No.
Normal Duty Heavy Duty
Output
Current (A)HP kW HP kW
100...120V AC (-15%, +10%) – 1-Phase Input, 0...230V 3-Phase Output
0.25 0.2 0.25 0.2 1.6 85...132 A 25-PM1-V1P6
0.5 0.4 0.5 0.4 2.5 85...132 A 25-PM1-V2P5
1.0 0.75 1.0 0.75 4.8 85...132 B 25-PM1-V4P8
1.5 1.1 1.5 1.1 6.0 85...132 B 25-PM1-V6P0
200...240V AC (-15%, +10%) – 1-Phase Input, 0...230V 3-Phase Output
0.25 0.2 0.25 0.2 1.6 170...264 A 25-PM1-A1P6
0.5 0.4 0.5 0.4 2.5 170...264 A 25-PM1-A2P5
1.0 0.75 1.0 0.75 4.8 170...264 A 25-PM1-A4P8
2.0 1.5 2.0 1.5 8.0 170...264 B 25-PM1-A8P0
3.0 2.2 3.0 2.2 11.0 170...264 B 25-PM1-A011
200...240V AC (-15%, +10%) – 1-Phase Input with EMC Filter, 0...230V 3-Phase Output
0.25 0.2 0.25 0.2 1.6 170...264 A 25-PM2-A1P6
0.5 0.4 0.5 0.4 2.5 170...264 A 25-PM2-A2P5
1.0 0.75 1.0 0.75 4.8 170...264 A 25-PM2-A4P8
2.0 1.5 2.0 1.5 8.0 170...264 B 25-PM2-A8P0
3.0 2.2 3.0 2.2 11.0 170...264 B 25-PM2-A011
200...240V AC (-15%, +10%) – 3-Phase Input, 0...230V 3-Phase Output
0.25 0.2 0.25 0.2 1.6 170...264 A 25-PM1-B1P6
0.5 0.4 0.5 0.4 2.5 170...264 A 25-PM1-B2P5
1.0 0.75 1.0 0.75 5.0 170...264 A 25-PM1-B5P0
2.0 1.5 2.0 1.5 8.0 170...264 A 25-PM1-B8P0
3.0 2.2 3.0 2.2 11.0 170...264 A 25-PM1-B011
5.0 4.0 5.0 4.0 17.5 170...264 B 25-PM1-B017
7.5 5.5 7.5 5.5 24.0 170...264 C 25-PM1-B024
10.0 7.5 10.0 7.5 32.2 170...264 D 25-PM1-B032
15.0 11.0 10.0 7.5 48.3 170...264 E 25-PM1-B048
20.0 15.0 15.0 11.0 62.1 170...264 E 25-PM1-B062
380...480V AC (-15%, +10%) – 3-Phase Input, 0...460V 3-Phase Output
0.5 0.4 0.5 0.4 1.4 323...528 A 25-PM1-D1P4
1.0 0.75 1.0 0.75 2.3 323...528 A 25-PM1-D2P3
2.0 1.5 2.0 1.5 4.0 323...528 A 25-PM1-D4P0
3.0 2.2 3.0 2.2 6.0 323...528 A 25-PM1-D6P0
5.0 4.0 5.0 4.0 10.5 323...528 B 25-PM1-D010
7.5 5.5 7.5 5.5 13.0 323...528 C 25-PM1-D013
10.0 7.5 10.0 7.5 17.0 323...528 C 25-PM1-D017
15.0 11.0 15.0 11.0 24.0 323...528 D 25-PM1-D024
20.0 15.0 15.0 11.0 30.0 323...528 D 25-PM1-D030

Allen-Bradley PowerFlex 523 Specifications

General

Frequency	50/60 Hz
Dimensions	Varies by model
Weight	Varies by model
Output Voltage	0 to Input Voltage
Power Rating	0.4-22 kW
Control Method	Sensorless Vector Control
Enclosure	IP20
Communication	EtherNet/IP
Operating Temperature	-20 to 50°C (-4 to 122°F)
Storage Temperature	-40 to 85°C (-40 to 185°F)
Relative Humidity	5% to 95% (non-condensing)
Input Voltage	200-240V AC, 380-480V AC
Horsepower	0.5…30 Hp
