Rockwell Automation Publication 520-UM001G-EN-E - September 2014 91

Programming and Parameters Chapter 3

Terminal Block Group (continued)

t094 [Anlg In V Loss] Related Parameter(s): P043, P044, A426, A427

Sets the response to a loss of input. When the 0-10V input (or –10 to +10V) is used for any reference, any input less than 1V is reported as a signal loss. Input must exceed 1.5V for the

signal loss condition to end.

If enabled, this function affects any input that is being used as a speed reference, PID reference or PID setpoint in the drive.

Options 0 “Disabled” (Default)

1 “Fault (F29)”

2“Stop”

3“Zero Ref”

4“Min Freq Ref”

5“Max Freq Ref”

6“Key Freq Ref”

7“MOP Freq Ref”

8 “Continu Last”

t095 [Anlg In4-20mA Lo] Related Parameter(s): P043, t096

Stop drive before changing this parameter.

Sets the percentage (based on 4-20 mA) of input current applied to the 4-20 mA analog input used to represent P043 [Minimum Freq].

Analog inversion can be accomplished by setting this value larger than t096 [Anlg In4-20mA Hi].

Values Default: 0.0%

Min/Max: 0.0/100.0%

Display: 0.1%

t096 [Anlg In4-20mA Hi] Related Parameter(s): P044, t095

Stop drive before changing this parameter.

Sets the percentage (based on 4-20 mA) of input current applied to the 4-20 mA analog input used to represent P044 [Maximum Freq].

Analog inversion can be accomplished by setting this value smaller than t095

[Anlg In4-20mA Lo].

Values Default: 100.0%

Min/Max: 0.0/200.0%
