Allen-Bradley PowerFlex 70 Enhanced Control User Manual

Engineering Parameters 119
UTILITY
Diag-Vector Cntl
532 [Ki Slip Reg]
Integral gain for the slip frequency regulator.
Default:
Min/Max:
Units:
64
0/32767
1
✔✔
533 [Flux Reg Enable]
Enables or disables the flux regulator.
Default:
Min/Max:
Units:
1
0/1
1
✔✔
534 [Kp Flux Reg]
Proportional gain for the flux regulator.
Default:
Min/Max:
Units:
64
0/32767
1
✔✔
535 [Ki Flux Reg]
Integral gain for the flux regulator.
Default:
Min/Max:
Units:
32
0/32767
1
✔✔
536 [Ki Flux Braking]
Proportional gain for the Flux Regulator.
Default:
Min/Max:
Units:
100
0/32767
1
✔✔
537 [Kp Flux Braking]
Integral gain for the Flux Regulator.
Default:
Min/Max:
Units:
500
0/32767
1
✔✔
538 [Rec Delay Time]
The delay that is enforced after a stop event prior to a
flying start event. A setting of 1000 = 0.5 seconds.
Default:
Min/Max:
Units:
1000
1/30000
1
✔✔
539 Freq Reg Kp
Proportional gain for frequency portion of torque
regulator in FVC encoderless mode.
Default:
Min/Max:
Units:
450
0/32767
N/A
✔✔
540 Freq Reg Ki
Integral gain for frequency portion of torque regulator
in FVC encoderless mode.
Default:
Min/Max:
Units:
2000
0/32767
N/A
✔✔
541 Encdlss Ang Comp
Voltage vector angle compensation for long motor
cables and switching characteristics in FVC
encoderless mode. 1024 = 1 revolution.
Default:
Min/Max:
Units:
0
-1023/+1023
N/A
✔✔
542 Encdlss Vlt Comp
Voltage compensation for long motor cables and
switching characteristics in FVC encoderless mode.
Default:
Min/Max:
Units:
12.8
0/Rated Volts x 0.5
VAC
✔✔
543 Excitation Ki
Integral gain for current regulator during excitation
phase of flying start.
Default:
Min/Max:
Units:
44
0/32767
N/A
✔✔
544 Excitation Kp
Proportional gain for current regulator during
excitation phase of flying start.
Default:
Min/Max:
Units:
1800
0/32767
N/A
✔✔
545 In Phase Loss Lvl
Sensitivity of input phase loss detection. 325 = 8.1V
DC bus ripple. (ripple volts/AC input VAC)
2
x 2
20
=
setting.
Default:
Min/Max:
Units:
325
10/1000
N/A
✔✔
546 Out Phase Loss Lvl
Sensitivity of output phase loss detection.200 is
approximately 5% drive rated current.
Default:
Min/Max:
Units:
200
1/400
N/A
✔
547 Ki Fast Braking
Integral gain for Fast Braking mode.
Default:
Min/Max:
Units:
1000
0/32767
N/A
✔✔
548 Kp Fast Braking
Proportional gain for Fast Braking mode.
Default:
Min/Max:
Units:
2000
0/32767
N/A
✔✔
File Group No.
Parameter Name & Description Values
PF 70 PF 700 PF700H
