PowerFlex 700VC Block Diagrams 153
PowerFlex 700VC
Block Diagrams
70EC
700VC
700H
Analog In 1
96 - TB Man Ref Sel
0.0 Hz
11 - MOP Frequency
Bit 13 - Spd Ref ID
271 - Drive Logic Rslt
Bit 12 - Spd Ref ID
271 - Drive Logic Rslt
10.0
102 - Preset Speed 2
Changeable Parameter=
=
=
=
=
Read Only Parameter
Bit Parameter - Not Set (0)
Bit Parameter - Set (1)
Parameter is Read Only
while Drive is Running
682.7 VDC
12 - DC Bus Voltage
0.0 VAC
6 - Output Voltage
0.0 Amps
3 - Output Current
0.0 Hz
1 - Output Freq
0.0
2 - Commanded Speed
0.0 %
24 - Commanded Torque
0.0
25 - Speed Feedback
0.0
415 - Encoder Speed
Motor
Gear
Load
E
1
Drive Control
Control Inputs & Outputs
Communication
Adapters
Network
Sensrls Vect
53 - Motor Cntl Sel
0.0 Hz
23 - Speed Reference
0.0
25 - Speed Feedback
0.0 %
138 - PI Output Meter
0.0 Hz
1 - Output Freq
0.0 Amps
441 - Torq Current Ref
Open Loop
80 - Feedback Select
Moto
r
Gear
Load
E
1
V/Hz &
Vector
Control
Current
Processing
V/Hz Control
Vector Control
Process
Control
Speed
Control
Reference
Speed Control
Regulator
Drive Overview
Control Overview

Related product manuals
