Allen-Bradley PowerFlex 70 Enhanced Control User Manual

Preface
Overview
The purpose of this manual is to provide detailed drive information including
operation, parameter descriptions and programming.
Manual Conventions This manual covers the PowerFlex 70EC and the PowerFlex 700VC Drives. Some
of the information presented applies to specific drives. The following symbols will
be used throughout to identify specific drive information.
Reference Materials In addition to the User Manual for your drive, the following manuals are
recommended for general drive information:
For Allen-Bradley Drives Technical Support:
To help differentiate parameter names and LCD display text from other text, the
following conventions will be used:
• Parameter Names will appear in [brackets]. For example: [DC Bus Voltage].
• Display Text will appear in “quotes.” For example: “Enabled.”
• The following words are used throughout the manual to describe an action:
Symbol Information pertains to …
PowerFlex 70 Enhanced Control (EC) drive
PowerFlex 700 Vector Control (VC) drive
70EC
700V
C
700H
✔
70EC
700V
C
700H
✔
Title Publication Available Online at . . .
Wiring and Grounding Guidelines for PWM AC
Drives
DRIVES-IN001…
www.rockwellautomation.
com/literature
Preventive Maintenance of Industrial Control and
Drive System Equipment
DRIVES-TD001…
Safety Guidelines for the Application, Installation
and Maintenance of Solid State Control
SGI-1.1
Title Online at . . .
Allen-Bradley Drives Technical Support
www.ab.com/support/abdrives
Word Meaning
Can Possible, able to do something
Cannot Not possible, not able to do something
May Permitted, allowed
Must Unavoidable, you must do this
Shall Required and necessary
Should Recommended
Should Not Not recommended
