Allen-Bradley PowerFlex 70 Reference Manual

Start-Up 2-199
Figure 2.40 PowerFlex 700 Vector Control Option Startup (9)
Flux Vector Start Up (S.M.A.R.T.)
8-1
8-2
8-3
8-4
8-5
8-6
8-7
8-8
8-9
8-10
Start-Up
SMART
Enter choice of
Speed units:
<Hz>
RPM
8-0
Start-Up
SMART
Enter value for
Digital In 2 Sel
5
Start
Start-Up
SMART
Enter value for
Minimum Speed
0.0 Hz
Start-Up
SMART
Enter value for
Maximum Speed
60.0 Hz
Start-Up
SMART
Enter value for
Accel Time 1
10.0 Secs
Start-Up
SMART
Enter value for
Decel Time 1
10.0 Secs
Start-Up
SMART
Enter value for
Speed Ref A Sel
Analog In 2
Start-Up
SMART
Enter value for
Motor NP FLA
0.8 Amps
Start-Up
SMART
Enter value for
Motor OL Hertz
10.0 Hz
Start-Up
SMART
Enter value for
Motor OL Factor
1.0
Start-Up
2. Motr Dat/Ramp
Enter choice for
Stop Mode A
Coast
<Ramp>
Ramp to Hold
DC Brake
Start-Up
SMART
SMART Startup
is now complete.
8-11

Allen-Bradley PowerFlex 70 Specifications

General

Input Voltage	200-240V AC, 380-480V AC, 500-600V AC
Frequency Range	0 - 400 Hz
Humidity	5% to 95% non-condensing
Output Voltage	0 to Input Voltage
Control Methods	Sensorless Vector Control
Communications	Ethernet/IP, DeviceNet, ControlNet
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Ground Fault
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Enclosure Rating	IP20, NEMA Type 1
