Allen-Bradley PowerFlex 70 Installation Instructions

4 Rockwell Automation Publication 20A-IN009E-EN-P - January 2015
PowerFlex 70 Adjustable Frequency AC Drive
Catalog Number Explanation
This table provides a description of the drive catalog numbers.
See Catalog Number Explanation (Continued) on page 5
.
Position Number
a
Drive
Code Type
20A PowerFlex 70
b
Voltage Rating
Code Voltage Ph.
B 240V AC 3
C 400V AC 3
D 480V AC 3
E 600V AC 3
c1
ND Rating
208V, 60 Hz Input
Code Amps kW (Hp) Frame
(1)
2P2 2.5 0.37 (0.5) A
4P2 4.8 0.75 (1.0) A
6P8 7.8 1.5 (2.0) B
9P6 11 2.2 (3.0) B
015 17.5 4.0 (5.0) C
022 25.3 5.5 (7.5) D
028 32.2 7.5 (10) D
042 43 11 (15) D
054 62.1 15 (20) E
070 78.2 18.5 (25) E
c2
ND Rating
240V, 60 Hz Input
Code Amps kW (Hp) Frame
(1)
2P2 2.2 0.37 (0.5) A
4P2 4.2 0.75 (1.0) A
6P8 6.8 1.5 (2.0) B
9P6 9.6 2.2 (3.0) B
015 15.3 4.0 (5.0) C
022 22 5.5 (7.5) D
028 28 7.5 (10) D
042 42 11 (15) D
054 54 15 (20) E
070 70 18.5 (25) E
c3
ND Rating
400V, 50 Hz Input
Code Amps kW (Hp) Frame
(1)
1P3 1.3 0.37 (0.5) A
2P1 2.1 0.75 (1.0) A
3P5 3.5 1.5 (2.0) A
5P0 5.0 2.2 (3.0) B
8P7 8.7 4.0 (5.0) B
011 11.5 5.5 (7.5) C
015 15.4 7.5 (10) C
022 22 11 (15) D
030 30 15 (20) D
037 37 18.5 (25) D
043 43 22 (30) D
060 60 30 (40) E
072 72 37 (50) E
c4
ND Rating
480V, 60 Hz Input
Code Amps kW (Hp) Frame
(1)
1P1 1.1 0.37 (0.5) A
2P1 2.1 0.75 (1.0) A
3P4 3.4 1.5 (2.0) A
5P0 5.0 2.2 (3.0) B
8P0 8.0 3.7 (5.0) B
011 11 5.5 (7.5) C
014 14 7.5 (10) C
022 22 11 (15) D
027 27 15 (20) D
034 34 18.5 (25) D
040 40 22 (30) D
052 52 30 (40) E
065 65 37 (50) E
c5
ND Rating
600V, 60 Hz Input
Code Amps kW (Hp) Frame
(1)
0P9 0.9 0.37 (0.5) A
1P7 1.7 0.75 (1.0) A
2P7 2.7 1.5 (2.0) A
3P9 3.9 2.2 (3.0) B
6P1 6.1 4.0 (5.0) B
9P0 9.0 5.5 (7.5) C
011 11 7.5 (10) C
017 17 11 (15) D
022 22 15 (20) D
027 27 18.5 (25) D
032 32 22 (30) D
041 41 30 (40) E
052 52 37 (50) E
CE certication testing has not been
performed on 600V class drives.
d
Enclosure
Code Enclosure
A
Panel Mount - IP20, NEMA/UL
Type 1
C
Wall/Machine Mount = IP66,
NEMA/UL Type 4X/12 for
indoor use only
F
Flange Mount - Front Chassis =
IP20, NEMA/UL Type 1; Rear
Heatsink = IP66, NEMA/UL
Type 4X/12 for indoor/outdoor
use
G
Wall/Machine Mount - IP54,
NEMA/UL Type 12
IP20 and IP66 frame E drives are manufactured
with a ange-like heatsink with mounting holes.
e
HIM
Code Interface Module
0 Blank Cover
3 Full Numeric LCD
5 Prog. Only LCD
Only available with NEMA 4X, option C.
(1) Frame size is dependent upon enclosure type and emission class. See Table 2 - Power Ratings on page 11 for applicable frame sizes for power ratings.
1-3 4 5-7 8 9 10 11 12 13 14 15 16
a bcde f gh i j k l
20A 2P2
0
BA
3
YA
Y NNC
Only available on Frame E.
Aotewell Ltd
www.aotewell.com
Industry Automation
HongKong|UK|China
sales@aotewell.com
+86-755-8660-6182

Allen-Bradley PowerFlex 70 Specifications

General

Input Voltage	200-240V AC, 380-480V AC, 500-600V AC
Frequency Range	0 - 400 Hz
Humidity	5% to 95% non-condensing
Output Voltage	0 to Input Voltage
Control Methods	Sensorless Vector Control
Communications	Ethernet/IP, DeviceNet, ControlNet
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Ground Fault
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Enclosure Rating	IP20, NEMA Type 1
