Allen-Bradley PowerFlex 70 Installation Instructions

Rockwell Automation Publication 20A-IN009E-EN-P - January 2015 11
PowerFlex 70 Adjustable Frequency AC Drive
Power Ratings, Dimensions, and Approximate Weights
This section provides power ratings, dimensions, and weights for the drives.
Table 2 - Power Ratings
Output Power Frame Size
kW
ND (HD)
Hp
ND (HD)
208…240V AC Input 400…480V AC Input 600V AC Input
Not
Filtered
(1)
Filtered
(2)
IP66 NEMA/UL
Type 4X/12
(3)
Not
Filtered
(1)
Filtered
(2)
IP66 NEMA/UL
Type 4X/12
(3)
Not
Filtered
(1)
Filtered
(2)
IP66 NEMA/UL
Type 4X/12
(3)
0.37 (0.25) 0.5 (0.33) A B B A B B A – B
0.75 (0.55) 1 (0.75) A B B A B B A – B
1.5 (1.1) 2 (1.5) B B B A B B A – B
2.2 (1.5) 3 (2) B B B B B B B – B
4 (3) 5 (3) – C D B B B B – B
5.5 (4) 7.5 (5) – D D – C D C – D
7.5 (5.5) 10 (7.5) – D D – C D C – D
11 (7.5) 15 (10) – D D – D D D – D
15 (11) 20 (15) – E E – D D D – D
18.5 (15) 25 (20) – E E – D D D – D
22 (18.5) 30 (25) – – – – D D D – D
30 (22) 40 (30) – – – – E E – E E
37 (30) 50 (40) – – – – E E – E E
(1) Not filtered is indicated if position 13 of the catalog number = N.
(2) Filtered is indicated if position 13 of the catalog number = A.
(3) For indoor use only.
Aotewell Ltd
www.aotewell.com
Industry Automation
HongKong|UK|China
sales@aotewell.com
+86-755-8660-6182

Allen-Bradley PowerFlex 70 Specifications

General

Input Voltage	200-240V AC, 380-480V AC, 500-600V AC
Frequency Range	0 - 400 Hz
Humidity	5% to 95% non-condensing
Output Voltage	0 to Input Voltage
Control Methods	Sensorless Vector Control
Communications	Ethernet/IP, DeviceNet, ControlNet
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Ground Fault
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Enclosure Rating	IP20, NEMA Type 1
