Allen-Bradley PowerFlex 70 - Page 12

12 Rockwell Automation Publication 20A-IN009E-EN-P - January 2015
PowerFlex 70 Adjustable Frequency AC Drive
Figure 2 - Dimension Drawings
Table 3 - Dimensions and Approximate Weights
A
E
B
D
F
C
B
A
C
D E
IP20 and IP66 NEMA/UL Type 1 and 4X/12 Flange Mount
Frame
Dimensions, mm (in.)
Weight
(2)
kg (lb)
(2) Approximate weights include the HIM.
ABCDEF
IP20 NEMA/UL Type 1
A 122.4
(4.82)
225.7
(8.89)
179.8
(7.08)
94.2
(3.71)
211.6
(8.33)
5.8
(0.23)
2.71 (6.0)
B 171.7
(6.76)
234.6
(9.24)
179.8
(7.08)
122.7
(4.83)
220.2
(8.67)
5.8
(0.23)
3.60 (7.9)
C 185.0
(7.28)
300.0
(11.81)
179.8
(7.08)
137.6
(5.42)
285.6
(11.25)
5.8
(0.23)
6.89 (15.2)
D 219.9
(8.66)
350.0
(13.78)
179.8
(7.08)
169.0
(6.65)
335.6
(13.21)
5.8
(0.23)
9.25 (20.4)
E 280.3
(11.04)
(1)
(1) IP20 and IP66 frame E drives are manufactured with a flange-like heatsink with mounting holes.
555.8
(21.88)
207.1
(8.15)
200.0
(7.87)
491.0
(19.33)
6.9
(0.27)
18.60 (41.0)
IP66 NEMA/UL Type 4X/12 (for Indoor Use Only)
B 171.7
(6.76)
239.8
(9.44)
203.3
(8.00)
122.7
(4.83)
220.2
(8.67)
5.8
(0.23)
3.61 (8.0)
D 219.9
(8.66)
350.0
(13.78)
210.7
(8.29)
169.0
(6.65)
335.6
(13.21)
5.8
(0.23)
9.13 (20.1)
E 280.3
(11.04)
(1)
555.8
(21.88)
219.8
(8.65)
200.0
(7.87)
491.0
(19.33)
6.9
(0.27)
18.60 (41.0)
Flange Mount
A 156.0
(6.14)
225.8
(8.89)
178.6
(7.03)
123.0
(4.84)
55.6
(2.19)
– 2.71 (6.0)
B 205.2
(8.08)
234.6
(9.24)
178.6
(7.03)
123.0
(4.84)
55.6
(2.19)
– 3.60 (7.9)
C 219.0
(8.62)
300.0
(11.81)
178.6
(7.03)
123.0
(4.84)
55.6
(2.19)
– 6.89 (15.2)
D 248.4
(9.78)
350.0
(13.78)
178.6
(7.03)
123.0
(4.84)
55.6
(2.19)
– 9.25 (20.4)
E 280.3
(11.04)
555.8
(21.88)
207.1
(8.15)
117.2
(4.61)
89.9
(3.54)
– 18.60 (41.0)
