Allen-Bradley PowerFlex 70 Installation Instructions

Rockwell Automation Publication 20A-IN009E-EN-P - January 2015 13
PowerFlex 70 Adjustable Frequency AC Drive
Figure 3 - PowerFlex 70 IP20 NEMA/UL Type 1 Bottom View Dimensions, mm (in.)
42.7 (1.68)
55.4 (2.18)
79.3 (3.12)
85.1 (3.35)
23.9 (0.94)
34.5 (1.36)
86.4 (3.40)
22.2 (0.87) Dia.
4 Places
102.4
(4.03)
129.8
(5.11)
135.9
(5.35)
155.2
(6.11)
163.7
(6.45)
55.6 (2.19)
75.5 (2.97)
85.7 (3.37)
113.5 (4.47)
123.8 (4.87)
127.5 (5.02)
43.4 (1.71)
32.8 (1.29)
101.6
(4.00)
126.2
(4.97)
136.7
(5.38)
155.2
(6.11)
163.7
(6.45)
22.2 (0.87) Dia.
5 Places
Frame A
(For some drive ratings, the fan is not present.)
Frame B
108.0 (4.25)
159.0 (6.26)
210.0 (8.27)
126.9
(4.99)
139.9
(5.50)
181.5
(7.14)
210.0 (8.27)
108.0 (4.25)
22.2
(0.87)
43.7
(1.72)
165.0
(6.49)
37.5 (1.48)
64.0 (2.52)
93.0 (3.66)
121.0 (4.76)
149.7 (5.89)
69.3 (2.73)
58.6 (2.31)
103.2
(4.06)
134.7
(5.30)
155.2
(6.11)
164.1
(6.46)
28.5 (1.12) Dia.
2 Places
22.2 (0.87) Dia.
2 Places
36.1 (1.42)
56.1 (2.21)
75.2 (2.96)
94.2 (3.71)
47.7 (1.88)
58.4 (2.30)
112.3 (4.42)
101.3
(3.99)
129.3
(5.09)
155.2
(6.11)
163.5
(6.44)
22.2 (0.87) Dia.
4 Places
Frame DFrame C
Frame E
Aotewell Ltd
www.aotewell.com
Industry Automation
HongKong|UK|China
sales@aotewell.com
+86-755-8660-6182

Allen-Bradley PowerFlex 70 Specifications

General

Input Voltage	200-240V AC, 380-480V AC, 500-600V AC
Frequency Range	0 - 400 Hz
Humidity	5% to 95% non-condensing
Output Voltage	0 to Input Voltage
Control Methods	Sensorless Vector Control
Communications	Ethernet/IP, DeviceNet, ControlNet
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Ground Fault
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Enclosure Rating	IP20, NEMA Type 1
