Allen-Bradley PowerFlex 70 Installation Instructions

14 Rockwell Automation Publication 20A-IN009E-EN-P - January 2015
PowerFlex 70 Adjustable Frequency AC Drive
Figure 4 - PowerFlex 70 IP 66 NEMA/UL Type 4X/12 Bottom View Dimensions, mm (in.)
(for indoor use only)
Figure 5 - PowerFlex 70 IP 54 / IP 66 NEMA/UL Type 4X/12 Bottom View Dimensions, mm (in.)
55.2 (2.17)
77.3 (3.04)
99.6 (3.92)
115.9 (4.56)
99.6
(3.92)
138.2
(5.44)
28.3
(1.11)
22.1
(0.87)
31.0 (1.22)
49.1 (1.93)
75.5 (2.97)
102.0 (4.02)
120.1 (4.73)
102.9
(4.05)
138.6
(5.46)
140.5
(5.53)
28.3
(1.11)
22.1
(0.87)
Frame B Frame D
108.2 (4.26)
157.7 (6.21)
165.7 (6.52)
207.7 (8.18)
22.5
(0.89)
44.5
(1.75)
124.9
(4.92)
139.9
(5.51)
163.4
(6.43)
Frame E
