Allen-Bradley PowerFlex 70 Installation Instructions

Rockwell Automation Publication 20A-IN009E-EN-P - January 2015 15
PowerFlex 70 Adjustable Frequency AC Drive
Figure 6 - PowerFlex 70 Flange Mount Bottom View Dimensions, mm (in.)
108.0 (4.25)
159.0 (6.26)
210.0 (8.27)
39.8
(1.57)
52.8
(2.08)
94.4
(3.72)
210.0 (8.27)
108.0 (4.25)
22.2
(0.87)
43.7
(1.72)
77.9
(3.07)
72.4 (2.85)
59.6 (2.35)
96.1 (3.78)
101.9 (4.01)
40.7 (1.60)
51.3 (2.02)
103.2 (4.06)
22.2 (0.87) Dia.
4 Places
43.2
(1.70)
70.5
(2.78)
76.6
(3.02)
95.9
(3.78)
104.4
(4.11)
53.1 (2.09)
73.0 (2.87)
92.2 (3.63)
111.2 (4.38)
64.7 (2.55)
75.4 (2.97)
129.3 (5.09)
40.6
(1.60)
68.7
(2.70)
94.6
(3.72)
102.9
(4.05)
22.2 (0.87) Dia.
4 Places
70.9 (2.79)
92.4 (3.64)
102.7 (4.04)
130.5 (5.14)
140.6 (5.54)
144.4 (5.69)
60.3 (2.37)
49.7 (1.96)
41.4
(1.63)
65.9
(2.59)
76.6
(3.02)
95.0
(3.74)
103.5
(4.07)
22.2 (0.87) Dia.
5 Places
51.9 (2.04)
78.3 (3.08)
107.3 (4.22)
135.5 (5.33)
164.1 (6.46)
83.7 (3.30)
73.0 (2.87)
42.3
(1.67)
74.1
(2.92)
94.6
(3.27)
103.5
(4.07)
28.5 (1.12) Dia.
2 Places
22.2 (0.87) Dia.
2 Places
Frame A
Frame B Frame D
Frame C
Frame E
Aotewell Ltd
www.aotewell.com
Industry Automation
HongKong|UK|China
sales@aotewell.com
+86-755-8660-6182

Allen-Bradley PowerFlex 70 Specifications

General

Input Voltage	200-240V AC, 380-480V AC, 500-600V AC
Frequency Range	0 - 400 Hz
Humidity	5% to 95% non-condensing
Output Voltage	0 to Input Voltage
Control Methods	Sensorless Vector Control
Communications	Ethernet/IP, DeviceNet, ControlNet
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Ground Fault
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Enclosure Rating	IP20, NEMA Type 1
