Allen-Bradley powerflex 700 Selection Guide

PowerFlex® 700 and 700S Product Selection 1-3
Drive Unit Options
Table 1.B PowerFlex® 700 and 700S Drives
Options Available to All Units:
Option Option Code Description
Control Power
Source
(1)(6)
6P Individual 115V AC-secondary, control power transformer (supplied per drive unit). Includes primary fusing
6TB 115V AC control power, factory wired from 115V AC control bus to drive unit (requires control bus)
6SC 115V AC control power supplied by customer
Auxiliary Contact for
Disconnect
(3)
98 (1) normally open (Y = option avail.)
99 (1) normally closed (Y = option avail.)
Wire Label Upgrade
Option
(10)
14WLBL Brady Datab™ wire labels
T-Handles
(2)
111 T-handles on doors and 3” vertical wireway (present in MCC sections containing frame 0, 1, 2, & 3 drive units
110 Standard handles
Door-Mounted
Devices
(4)
1ES Hardwired-interface-stop-pushbutton; for drive-disable function
4EA Control-power-on pilot light
4EW Drive-faulted pilot light
Miscellaneous J11 Audio phone jack
J12 115V AC, 15A, duplex receptacle
Unit Door
Nameplates
(1)
M3EW Phenolic label with white background and black lettering
N3EB Phenolic label with black background and white lettering
N3ER Phenolic label with red background and white lettering
Communication
Adapters
(1)(15)
14PNA No Communication adapter
14PCNC DPI - ControlNet adapter, coaxial cable
14PCNF DPI - ControlNet adapter, fiber optic
14PDF1 DPI - RS485 DF-1 adpater
14PDPV1 DPI - PROFIBUS DPV-1 adapter
14PEA DPI - Ethernet adapter
14PG1 DPI - Single-Point Remote I/O (RIO) adapter
14PG5 DPI - DeviceNet adapter
14PHVA DPI - RS485 HVAC adapter (future)
14PIB DPI - Interbus adapter (future)
14PLW DPI - LonWorks® adapter (future)
Communication
Adpater (PowerFlex
700S with DriveLogix
Only)
(1)(15)
14DLD ELC - DeviceNet adapter
14DLE ELC - EtherNet adapter
14DLOC ELC - ControlNet adapter, coaxial cable
14DLOF ELC - ControlNet adapter, fiber optic
14DLORC ELC - ControlNet Redundant adapter, coaxial cable
14DLORF ELC - ControlNet Redundant adapter, fiber optic
Human Interface
Module (HIM)
(3)
14HAPC Door-mounted HIM, Programmer Only LCD
14HA3C Door-Mounted HIM with full numeric LCD
HA1C Drive-Mounted Him with analog LCD
HA2C Drive-Mounted HIM with digital LCD
HA3C Drive-Mounted HIM with full numeric LCD
HAP Door-Mounted HIM Programmer Only LCD
Drive Enclosure
(1)
14DO Open
14D1 NEMA 1
14D12 NEMA 12
14DF Flange

Allen-Bradley powerflex 700 Specifications

General

Series	PowerFlex 700
Category	AC Drive
Input Voltage	200-240V AC, 380-480V AC, 500-600V AC
Enclosure	Type 1
Control Method	Sensorless Vector
Communication	EtherNet/IP, ControlNet, DeviceNet, PROFIBUS DP, Modbus
