2-2 1336 PLUS™ Variable Frequency, 1336 PLUS™ II, 1336 FORCE - Vector Control, 1336 IMPACT Product Selection
Frame Selection
The following table is used to determine the frame size required based on
the desired Drive Type, Input Voltage and Horsepower.
Table 2.A 1336 Frame Selection
1336 Frame Sizes
Drive
Type
Code
Input Voltage
A
(1.5 SF
20” Wide)
B
(2.5 SF
20” Wide)
C
(3.5 SF
20” Wide)
D
(6.0 SF
20” Wide)
E
(6.0 SF
25” Wide)
F
(6.0 SF
35” Wide)
G
(6.0 SF
35” Wide)
H
(6.0 SF
35” Wide)
1336S PLUS
E 230V AC 0.5 - 5.0 HP 7.5 - 15 HP 10 - 30 HP NA
(1)
NA NA NA NA
380/460V AC 0.5 - 5.0 HP 7.5 - 30 HP 40 - 50 HP 60 - 125 HP 150 - 250 HP 300 - 400 HP 450 - 600 HP NA
575V AC 1, 3 HP 7.5 - 20 HP 25 - 60 HP 75 - 125 HP 150 - 300 HP 350 - 400 HP 450 - 650 HP NA
G 310V DC 0.5 - 5.0 HP 7.5 - 15 HP 10 - 30 HP NA NA NA NA NA
512/620V DC 0.5 - 5.0 HP 7.5 - 30 HP 40 - 50 HP 60 - 125 HP 150 - 250 HP 300 - 400 HP 450 - 600 HP NA
775V DC 1, 3 HP 7.5 - 20 HP 25 - 60 HP 75 - 125 HP 150 - 300 HP 350 - 400 HP 450 - 650 HP NA
1336T FORCE
F 230V AC NA 1, 3, 7.5 - 15 HP 20 - 30 HP NA NA NA NA NA
380/460V AC NA 1, 3, 7.5 - 30 HP 40 - 50 HP 60 - 125 HP 150 - 250 HP 300 - 400 HP 450 - 600 HP NA
575V AC NA 1, 3, 7.5 - 20 HP 25 - 60 HP 75 - 125 HP 150 - 300 HP 350 - 400 HP 450 - 650 HP NA
H 310V DC NA 1, 3, 7.5 - 15 HP 20 - 30 HP NA NA NA NA NA
512/620V DC NA 1, 3, 7.5 - 30 HP 40 - 50 HP 60 - 125 HP 150 - 250 HP 300 - 400 HP 450 - 600 HP 700, 800 HP
775V DC NA 1, 3, 7.5 - 20 HP 25 - 60 HP 75 - 125 HP 150 - 300 HP 350 - 400 HP 450 - 650 HP 700, 800 HP
1336E IMPACT
L 230V AC 0.5 - 5.0 HP 7.5 - 15 HP 10 - 30 HP NA NA NA NA NA
380/460V AC 0.5 - 5.0 HP 7.5 - 30 HP 40 - 50 HP 60 - 125 HP 150 - 250 HP 300 - 400 HP 450 - 600 HP NA
575V AC 1, 3 HP 7.5 - 20 HP 25 - 60 HP 75 - 125 HP 150 - 300 HP 350 - 400 HP 450 - 650 HP NA
M 310V DC 0.5 - 5.0 HP 7.5 - 15 HP 10 - 30 HP NA NA NA NA NA
512/620V DC 0.5 - 5.0 HP 7.5 - 30 HP 40 - 50 HP 60 - 125 HP 150 - 250 HP 300 - 400 HP 450 - 600 HP 700, 800 HP
775V DC 1, 3 HP 7.5 - 20 HP 25 - 60 HP 75 - 125 HP 150 - 300 HP 350 - 400 HP 450 - 650 HP 700, 800 HP
A
(1.5 SF <= 5 HP
2.5 SF >5 HP
20” Wide)
B
(2.5 SF
20” Wide)
C
(3.5 SF
20” Wide)
D
(6.0 SF
20” Wide)
E
(6.0 SF
25” Wide)
F
(6.0 SF
35” Wide)
G
(6.0 SF
35” Wide)
H
(6.0 SF
35” Wide)
1336F PLUS II
N 230V AC 0.5 - 5.0 HP 7.5 - 15 HP 20 - 30 HP NA NA NA NA NA
380/460V AC 0.5 - 15 HP 20 - 30 HP 40 - 50 HP 60 - 125 HP 150 - 250 HP 300 - 400 HP 450 - 600 HP NA
575V AC 0.5 - 20 HP 7.5 - 20 HP 25 - 60 HP 75 - 125 HP 150 - 300 HP 350 - 400 HP 450 - 650 HP NA
P 310V DC 0.5 - 5.0 HP 7.5 - 15 HP 20 - 30 HP NA NA NA NA NA
512/620V DC 0.5 - 15 HP 20 - 30 HP 40 - 50 HP 60 - 125 HP 150 - 250 HP 300 - 400 HP 450 - 600 HP NA
775V DC 0.5 - 20 HP 7.5 - 20 HP 25 - 60 HP 75 - 125 HP 150 - 300 HP 350 - 400 HP 450 - 650 HP NA
(1)
NA = Not Available

Allen-Bradley powerflex 700 Specifications

General

Series	PowerFlex 700
Category	AC Drive
Input Voltage	200-240V AC, 380-480V AC, 500-600V AC
Enclosure	Type 1
Control Method	Sensorless Vector
Communication	EtherNet/IP, ControlNet, DeviceNet, PROFIBUS DP, Modbus
