Motor Control Centers offer a convenient design for the configuration of
AC drive lineups. When configured in conjunction with a Bulletin 2100
main incoming structure, the CENTERLINE® thru-bus solution eliminates
the challenge of low-voltage power distribution for drives.
We designed this publication to help you configure AC drive equipment
within Bulletin 2100 CENTERLINE Motor Control Center (MCC)
sections. The selection tables in this publication will help you specify the
necessary sections and units.
Important: When using this publication, please be sure to read all
footnotes. Footnotes are used throughout this publication to
advise you of configuration and limitation of structures, units,
and options.
For PowerFlex® drive units listed in Table 1.A:
• select drive unit options using Table 1.B
• select MCC vertical sections selected using Table 3.A
For 1336 drive units listed in Table 2.A:
• elect drive unit options using Table 2.B
• select MCC vertical sections selected using Table 3.A
If there is a need to purchase a separately-assembled unit (for example, if a
spare unit is desired), select the unit as listed in Table 1.A or Table 2.A.
When constructing the catalog number string, use the “N” enclosure
designation for NO structure assembly.
Options or equipment not offered through the 2362 standard AC drive unit
program can be provided to you as an engineered solution. Contact your
local Rockwell Automation Drive Systems representative.
General Product Description
Bulletin 2362 AC motor drive units are specifically designed for use in
CENTERLINE® MCC lineups. You may select from numerous 1336
PLUS® Variable Frequency, 1336 PLUS® II Variable Frequency, 1336
FORCE Field-Oriented Control Vector, 1336 Impact, PowerFlex® 700, and
PowerFlex® 700S digital AC motor drives. You may have these drives
configured for either a common-AC or a common-DC power bus
configuration.
NEMA Class I, Type A-rated units are standard. To provide either a NEMA
Type 1 or a NEMA Type 1 with gaskets enclosure rating, the unit must be
installed into an appropriately-sized MCC vertical section. Terminals
