Allen-Bradley powerflex 700 Selection Guide

1336 PLUS™ Variable Frequency, 1336 PLUS™ II, 1336 FORCE - Vector Control, 1336 IMPACT Product Selection 2-3
Drive Unit Options
Table 2.B Drive Unit Options
Options Available to All Units:
Option Option Code Description
Control Power
Source
(1)(6)
6P Individual 115V AC-secondary, control power transformer (supplied per drive unit). Includes primary fusing
6TB 115V AC control power, factory wired from 115V AC control bus to drive unit (requires control bus)
6SC 115V AC control power supplied by customer
Auxiliary Contact
for
Disconnect
(3)(5)
Input Voltage >
Frame Size >
230V AC /
310V DC
380V AC /
460V AC
512V DC /
620V DC
575V AC 775V DC
A,B,C A,B,C,D,E F,G,H A,B,C,D,E F,G,H
98 (1) normally open (Y = option avail.) Y Y Y
99 (1) normally closed (Y = option avail.) Y Y Y
989 (1) normally open + (1) normally closed (Y = option
avail.)
YY
Wire Label
Upgrade
Option
(11)
14WLBL Brady Datab™ wire labels
T-Handles
(2)
111 T-handles on doors and 3” vertical wireway (present in MCC sections containing frame A, B, & C drive units
Door-Mounted
Devices
(4)
1ES Hardwired-interface-stop-pushbutton; for drive-disable function
4EA Control-power-on pilot light
4EB Drive-at-speed pilot light
4ER Drive-run pilot light
4EW Drive-faulted pilot light
Miscellaneous J11 Audio phone jack
J12 115V AC, 15A, duplex receptacle
Unit Door
Nameplates
(1)
M3EW Phenolic label with white background and black lettering
N3EB Phenolic label with black background and white lettering
N3ER Phenolic label with red background and white lettering
Communication
Adapters
(3)
14CN1 DPI - SCANport™ to ControlNet adapter
14G1 SCANport to Single-Point Remote I/O (RIO) adapter
14G2 SCANport to RS232/422/485, DF1, or DH485 adapter
14G5 SCANport to DeviceNet adapter
Human Interface
Module (HIM)
(3)
14HA1C Door-mounted HIM with analog potentiometer
14HA2C Door-mounted HIM with digital potentiometer
14HAPC Door-mounted HIM, Programmer Only LCD
14HNBC Door-mounted connector permitting connection of a hand-held HIM or GPT through closed-door unit
Options Available to 2362E & 2362G Units:
Option Option Code Description
Control Logic
Interface
Boards
(3)
14L5 24V DC
14L5E 24V DC with encoder feedback
14L6 115V AC
14L6E 115V AC with encoder feedback
Languages
(1)
14DE English/German
14EN English/English
14ES English/Spanish
14FR English/French
14IT English/Italian

Allen-Bradley powerflex 700 Specifications

General

Series	PowerFlex 700
Category	AC Drive
Input Voltage	200-240V AC, 380-480V AC, 500-600V AC
Enclosure	Type 1
Control Method	Sensorless Vector
Communication	EtherNet/IP, ControlNet, DeviceNet, PROFIBUS DP, Modbus
