Allen-Bradley powerflex 700 Selection Guide

Chapter 1
PowerFlex® 700 and 700S Product Selection
Catalog Number
Explanation
Use the following tables for determining the catalog number used to order
PowerFlex 700 and 700S drives in Bulletin 2362 MCCs.
2362 S A - 4 A B - 48 DA - OPTIONS
Drive Type
Q PowerFlex® 700 (AC Common Bus)
R PowerFlex® 700 (DC Common Bus)
S PowerFlex® 700S (AC Common Bus)
T PowerFlex® 700S (DC Common Bus)
Wiring Type
A“A” Type
B “A” Type Power Wiring with
Bottom Exit
T “A” Type Power Wiring with
Top E xit
Frame Size
See Table 1.A on
page 1-2
Enclosure
A NEMA Type 1 with no
gaskets or door fan filters
J NEMA Type 1 with gaskets
or door fan filters
Input Voltages
A 230V AC Bus
J 380V AC Bus
B 460V AC Bus
C 575V AC Bus
D 310V DC Bus
V 512V DC Bus
E 620V DC Bus
F 775V DC Bus
Horsepower Rating
(3)
85 0.33
33 0.5
34 0.75
35 1.0
36 1.5
37 2.0
38 3.0
39 5.0
40 7.5
41 10
42 15
43 20
44 25
45 30
46 40
47 50
48 60
49 75
50 100
51 125
52 150
54 200
56 250
57 300
58 350
59 400
60 450
61 500
62 600
63 650
64 700
66 800
Disconnect Type
DA Fused Disconnect
Options
See Table 1.B on page 1-3

Allen-Bradley powerflex 700 Specifications

General

Series	PowerFlex 700
Category	AC Drive
Input Voltage	200-240V AC, 380-480V AC, 500-600V AC
Enclosure	Type 1
Control Method	Sensorless Vector
Communication	EtherNet/IP, ControlNet, DeviceNet, PROFIBUS DP, Modbus
